4×2 Dongfeng 12 Ton Crane Tow Truck – Heavy Duty Recovery & Wrecker Vehicle | ||
---|---|---|
General | Vehicle Brand | shenbai |
Chassis Brand | Dongfeng | |
Overall Dimension | 9000*2550*3780mm | |
GVW / Kerb Weight | 18000kg/12800kg | |
Cab | Cab Capacity | 3 persons allowed |
Air Conditioner | Heating/cooling air conditioner | |
Fuel Type | Diesel | |
Engine Brand | YUCHAI | |
Power | 220hp | |
Emission Standard | Euro 6 | |
Chassis | Drive Type | 4×2 |
Transmission | FAST 8-speed gearbox | |
Wheelbase | 5100 | |
Tire Specification | 10.00R20 | |
Tire Number | 6+1(Spare tire) | |
Max Speed | 90km/h | |
Paint | Metallic paint | |
Upper Body | Crane Type | Telescopic boom crane |
Max. Lifting Capacity | 12000kg | |
Boom Number | 4 | |
Slewing Angle | 360°Infinite rotation | |
Crane Weight | 5600kg | |
Installation Space | 1040mm | |
Flatbed Dimension | 7200*2550mm | |
Optional | **Knuckle boom crane | |
**Remote control |
4×2 Dongfeng 12 Ton Crane Tow Truck – Heavy Duty Recovery & Wrecker Vehicle
4×2 Dongfeng 12 Ton Crane Tow Truck – Heavy Duty Wrecker for Recovery & Transport
Product Overview:
The 4×2 Dongfeng Crane Tow Truck is a professional-grade wrecker engineered for heavy-duty vehicle recovery and transport. Built on a reliable Dongfeng 4×2 chassis and equipped with a 12-ton hydraulic crane, this tow truck delivers unmatched lifting and towing capabilities for accident recovery, logistics, and construction sites. Ideal for towing companies, municipal services, and global B2B buyers seeking durable, high-performance equipment.
Key Features:
✔ 12-Ton Hydraulic Crane – 360° rotation with extended boom reach for flexible load handling.
✔ Dongfeng 4×2 Heavy-Duty Chassis – Powered by a 220HP+ diesel engine (customizable) for rugged terrain and long-haul operations.
✔ Multi-Function Towing System – Features hydraulic winch, adjustable tow arms, and wheel-lift/underlift for diverse recovery modes (flatbed, hook lift, etc.).
✔ Enhanced Safety & Durability – Reinforced steel frame, anti-corrosion coating, CE/ISO-certified, with LED warning lights for 24/7 visibility.
✔ B2B Customization – Optional add-ons: outriggers, toolboxes, GPS tracking, and OEM branding.
Technical Specifications:
Model | Dongfeng 4×2 Crane Tow Truck |
| Chassis | 4×2 Dongfeng Heavy Duty |
| Engine | 220HP Diesel (Euro III/IV/V compliant) |
| Max Crane Capacity | 12 Tons |
| Max Towing Weight | 30 Tons (flatbed configuration) |
| Crane Boom Length | 19.6 Meters (customizable) |
| Compliance | CE, ISO, DOT (export-ready) |
Industry Applications:
– Highway & Urban Accident Recovery – Quickly clear stalled trucks or buses.
– Logistics & Transport – Tow broken-down heavy trucks or trailers.
– Construction & Mining – Relocate excavators, loaders, and machinery.
– Government & Municipal Use – Emergency response fleets.
Why Choose Us?
✅ Global B2B Supplier – Export to 50+ countries with localized support.
✅ OEM/ODM Services – Custom branding, configurations, and bulk discounts.
✅ After-Sales – Spare parts network + 24/7 technical assistance.
Request a Quote Today! – Contact our sales team for competitive pricing, specs sheets, and delivery terms.
